Automatic Fried Instant Noodle Line 160000bags/8hours

Material: Flour
Capacity: 160000bags/8hours
Loading Port: Shanghai

Email: wendy@machinehall.com

Skype: wendymachinehall

Click For Offer Send Email

Details
Technical Data
Message

The Automatic Fried Instant Noodle Line includes Brine metrology mixer, Supply metering device, Double speed dough mixer, Disc curing machine, Single continuous rolling machine, Single-layer steamed noodles machine, Cutting and folding machine, Fried dryer, Strong Air cooling device, Shunt conveyor, Conveyor, Products conveyor, Electric control cabinet.

The whole instant noodle production line has unique production process, innovative design, safe and reliable, high degree of automation,that we take adopt up-to-date technology.

The following technical date is 160000bags/8h for reference. We also have 30000 bags/8h,60000 bags/8h,80000 bags/8h,100000bags/8h,and 200000bags/8h for your choice.

Related machine line ：
Bag instant noodle line,Cup instant noodle machine, Fried free instant noodle line

automatic fried instant noodle production line with best price china

automatic fried instant noodle production line with best price china

Automatic Fried Instant Noodle Line 160000bags/8hours
No	Equipments	Model	Quantity	Remark
1	Brine metrology mixer	LGYSH100	2set	1.5 kw, Pump power 0.75 kw, the capacity of 1000 l/units, contact with water for stainless steel surface
2	Supply metering device	LGYSJ10	1set	Volume of 110 liters with LCD., round of tank, stainless steel, the pump is 0.75 kw,
3	Double speed dough mixer	LGHMJ250	2set	power 11/14kw, 200 kg/pan, manually open the door, contact with the surface of stainless steel and nylon
4	Disc curing machine	LGXS250	1set	Power 4 kw, Tray 2000 mm x 410 mm and raw material for stainless steel surface contact
5	Single continuous rolling machine	LGMT10-90	1set	Paste width 650, 11+18.5=29.5kw power（Frequency control of motor speed), 10 pcs steel roller, Hands + worm mechanism adjustable thickness, roll diameter φ395×1, φ300×2, φ248×2, φ216*2, φ180×2, φ162×2,
6	Single-layer steamed noodles machine	LGCZM90	1set	Machine is 30 meters long, 3 kw power (VVVF), fan 0.37 kw x 2 units, water seal, mechanical lifting door, stainless steel
7	Cutting and folding machine	LGQF160	1set	Main drive 1.5 kw (frequency control of motor speed),air knife:0.9 kw, With spray device.
8	Fried dryer	LGYZ160	1set	The main drive 3kw (frequency control), lifting 2.2 kw, circulating pump 15 kw, gear pump 2.2 kw, air knife 0.9 kw × 2,100m2 spiral heat exchanger 1 Taiwan, 1.5 m3 + 4.5m3 each tank 1, carbon steel production
9	Strong Air cooling device	LGFL180	1 set	Blower: 0.37 kwx14 sets, exhaust fan 3 kw power supply by Fried, carbon steel plastic sheeting
10	Shunt conveyor	LGFS200	1 set	Main drive 1.1 kw (VVVF),
10	Conveyor	LGSS160	3set	0.37 kw x 3 main drive, mechanical control, stainless steel panel
11	Products conveyor	LGCS160	3set	w x 2 main drive, mechanical control, stainless steel panel
12	Electric control cabinet	LGBPT-1	1 set	The main process adopts frequency control of motor speed, PLC program control
